3/4 Axle Bulk Cargo Dump Hopper Bottom Trailer
- Constructed of high-strength steel, this trailer is designed to withstand the most demanding working conditions. Its precision-engineered frame ensures structural integrity even when fully loaded.
- The specially designed bottom bucket structure ensures quick and complete unloading, minimizing material backlog and improving operational efficiency.
- We offer a wide range of customization options, including varying capacity specifications, axle counts, specialized linings (suitable for corrosive materials), and automatic tarpaulin systems. Each trailer is tailored to specific customer needs, ensuring optimal performance and suitability.
Hopper Bottom Trailer Specifications
| Type | Hopper Bottom Trailer |
| Payload (kgs) | 88500 |
| Tare weight (kgs) | 8500 |
| Dimensions (mm) | 13500*2600*3900/Customizable |
| Material | Carbon steel/Aluminum |
| Main beam | Heavy duty H beam |
| Axle | 2/3/4 |
| Suspension | Mechanical suspension |
| Tire | 12R22.5 ,11R22.5 |
| Rim | 9.00-22.5,8.25-22.5,11.75-22.5 |
| Landing gear | 28 Ton two speed |
| Electrical | LED light , 7 ways , 24V |
| Color | Customizable |
| Accessory | Tool box |
