Gooseneck Dump Trailer Sale | 20K-40K Payload | Hydraulic Lift | Tow with 1-Ton Trucks

Heavy-Duty Gooseneck Dump Trailer | Premium Hauling & Unmatched Versatility

✅ Uncompromised Strength
• Frame: 8″ I-Beam (13 lb/ft) chassis + 3″ channel cross-members @ 12″ centers
• Axles: Dual premium 7,000# or 8,000# cambered axles w/ quick-lubricating hubs (15.9K/17.6K GVWR)
• Dumping Power: 12-ton 3-stage telescopic ram w/ power up/gravity down control

✅ Smart Productivity Design
• Effortless Loading: 6.5′ heavy-duty ramps + side access step
• Integrated Storage: Lockable pump/battery box + formed tarp shroud
• Safety Focus: Sealed wiring + rear stabilizers + Grade 70 safety chains

Category:
Get Factory Price
CATEGORY

Gooseneck Dump Trailer

SPECIFICATIONS
Axles (15.9K) 2 - 7000# Premium, Cambered Axles with Quick-Lubricating Hubs or (17.6K) 2 - 8000# Premium, Cambered Axles with Quick-Lubricating Hubs
Brakes Forward Self-Adjusting Electric Brakes on Both Axles
Suspension Multi-Leaf Slipper Spring w/ Equalizer
Tongue Fabricated I-Beam
Coupler 2-5/16" Adjustable Coupler
Safety Chains 3/8" Grade 70 w/ Safety Latch Hook (2 ea)
Jack 12,000# Top Wind,Drop Leg, Set-Back Jack
Frame 8" I-Beam, 13lbs. per foot
Cross-Members 3" Channel on 12" Centers
Floor 7 Ga
Fenders Double Broke
Ramps 6.5' Heavy Duty Ramps
Stake Pockets Stake Pockets Along Both Sides
Wiring Sealed Modular Wiring Harness
Tires ST235/80 R-16 Load Range E Radial Tires
Spare Mount Side Spare Tire Mount
Paint Type Sherwin Williams Super Durable Powder
Paint Color Black Gray
Tie-Downs (6) 5/8" D-Rings Inside Bed to Secure Equipment
Gate Rear Combo Gate (Barn Doors & Spreader Gate)
J-Hooks Along sides for Cargo Control
Power Power Up/Gravity Down Movement
Ram 12-Ton 3- Stage Telescopic Cylinder
Sides 24" Tall, 40" Optional
Stabilizers Rear Stabilizer Stands
Steps Convenient Side-Step to Access Top Rail
Storage Lockable Pump and Battery Box mounted in Front of Bed
