Single Axle Dump Trailers for Sale | 12K GVWR | Towable with F-150 | DOT Certified
Single Axle Dump Trailers for Sale | 12K GVWR | Towable with F-150 | DOT Certified - Image 2
Single Axle Dump Trailers for Sale | 12K GVWR | Towable with F-150 | DOT Certified - Image 3

Single Axle Dump Trailers for Sale | 12K GVWR | Towable with F-150 | DOT Certified

Ideal for contractors and landscapers, our agile single axle dump trailers deliver heavy-duty performance without the bulk:

Right-Sized Efficiency: 12-18 ft lengths with 10-14 ft beds (up to 10,000 lb payloads) – perfect for tight job sites.

Rapid Unloading: 12V electric hydraulic pump achieves 45°+ dumps in 20 seconds – no PTO needed!

Tow-Friendly: 7K-10K lb axles + GVWRs ≤14,000 lbs. Fits 3/4-ton trucks (F-250/RAM 2500) – No CDL required!

Built Tough: 10-gauge steel frames + 12-gauge diamond plate floors shrug off gravel, debris, and daily abuse.

Category:
Get Factory Price
Category Specification Notes
DIMENSIONS
Overall Length 12-18 ft (3.7-5.5 m) Compact footprint for maneuverability
Overall Width 82-83 in (2.08-2.11 m) Standard road-legal width
Bed Length (Inside) 10-14 ft (3.0-4.3 m) Optimized for single-axle stability
Bed Width (Inside) 76-78 in (1.93-1.98 m)
Side Height 24"-36" (0.61-0.91 m) Lower profile for balanced loading
CAPACITY & WEIGHT
Payload Capacity 6,000-10,000 lbs (2,700-4,500 kg) Ideal for midsize loads
GVWR 10,000-14,000 lbs (4,500-6,350 kg) Matches Class III/IV towing
Empty Weight (Tare) 2,800-4,200 lbs (1,270-1,900 kg) Lightweight design for fuel efficiency
AXLE & SUSPENSION
Axle Configuration Single Axle Key differentiator
Axle Capacity 7,000-10,000 lbs (3,175-4,535 kg) Dexter® or Rockwell® torsion axles
Suspension Type Leaf Spring or Torsion Low maintenance
HYDRAULIC SYSTEM
Pump Type 12V Electric Hydraulic Pump Integrated battery operation
Lift Time 20-30 seconds (full cycle) Rapid unloading
Dump Angle 45°-50° Efficient material clearance
BRAKES & TIRES
Brake System Electric Brakes (1 Axle) Breakaway kit included
Tires ST205/75R15 Load Range D (5,180 lbs cap.) 10-ply rated
STRUCTURE
Frame Material 10-Gauge Steel Channel Reinforced crossmembers
Bed Material 12-Gauge Floors / 14-Gauge Sides Diamond plate options available
COUPLER
Hitch Type 2" Ball Coupler
Coupler Rating 10,000-14,000 lbs (4,535-6,350 kg) Adjustable for height leveling
STANDARD FEATURES
Lighting LED Tail/Brake/Turn Signals Submersible connectors
Safety Breakaway System DOT compliant
KEY ADVANTAGES • Lower maintenance costs
• Easier towing & storage
• Faster dump cycles
• Ideal for skid steers, gravel, mulch, debris
