Hot Sale 3 Axle 80 Ton Side Dump Semi Trailer With Hydraulic System
Innovative side-dumping technology – Utilizing a precision-engineered hydraulic system, this machine achieves efficient and safe side-dumping, reducing unloading time.
Optimized tri-axle structure – A scientifically designed tri-axle configuration ensures optimal weight distribution and road stability, extending the machine’s service life.
Durable steel structure – Crafted from high-strength steel, it offers superior impact and wear resistance, making it suitable for harsh working environments.
Side Dump Semi Trailer Specifications
| Type | Side Dump Semi Trailer |
| Grade | Heavy Duty |
| Tread | 1820mm |
| Wheel Base | 8000-9000mm |
| ABS Anti-lock Braking System | ABS Anti-lock Braking System |
| Self-dumping | Self-dumping |
| Material | Steel |
| Loading Capacity | 80T |
| Wheel Base(mm) | 6100+1320+1320 |
| Kingpin | 50# or 90# |
| Steel Spring | 10/10/10 leaf spring suspension |
| Tyre and Quantity | 1200r20 12sets |
| Thickness | bottom:8mm, side:6mm |
| Painting | Customizable |
| Tool Box | 1 set |
